GW13 3 Phase Isolator Switch

1. GW13 type 40.5kv high voltage outdoor 3 phase isolator switch

GW13 type main transformer neutral is alternating current 50Hz outdoor electric equipment. In the event of

the no bearing, it used as the transformer neutral point to connect the ground. It also can be used as the

ground connecting equipment composed with the adjustable discharge gap, gap support isolated pillar and

current mutual inductor.
GW8-40.5~126/630 type and GW13-40.5~126/630~1250 type can mach CJ6 motor operating machine or

CS17-G mechanic operating machine.

2. Application

• Suitable Altitude: 1000m
• Suitable Temperature: -30℃ ~ +40℃
• Relative Humidity: Daily mean ≤95%, monthly mean ≤90%
• No conductivity dust.
• No insulation object with devastating metal and corrosive gas.
• No violent vibration and striking.
• No explosive danger and fire.

3. Drawing

4. Factory

5. Delivery

6. FAQ

1. Send the technical data, better for all useful information; we will make a good recommendation.

If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.

2. The lead time depend on quantity of order. Some standard type is on stock. Otherwise, it will take 3-15 days.

3. Usually shipped by sea, small order or urgent order we can send you by air.

4. All our activities are accredited to ISO 14001:2015 and IEC standard.

5. Technology ensure the quality satisfy international request.
